10. Specifications
Device Type ADX-32/ADX-64
No. 1003
ADAT Input/Output connector type Optical connector type F05 (TOSLINK ®)
Cat5 cable connector type Neutrik EtherCon® ruggedized connector,
compatible with standard RJ45 plugs
Transmission media Twisted pair network cable.(100 ohms) meeting or
exceeding Cat5 specifications.
DMX cabling (110 ohms) may also be used, however,
the maximum transmission distance may be reduced.
A customer specific version optimized for DMX
cabling, providing full transmission distance, is
available on request.
Maximum transmission distance (Cat5 bus end-to-end) 100m
Maximum number of devices on a Cat5 bus 32
Supported data formats ADAT Lightpipe®, S/PDIF®, AC3/Dolby Digital 5.1 ®,
DTS® and other data formats using TOSLINK® optical
connectors, up to 15.5 Mbit/s signalling rate.
All four connections work completely independent of
each other. It is therefore possible to transmit different
data formats, sample rates, resolutions at the same
time.
Converter latency (ADAT->Cat5, Cat5->ADAT) Each <50ns
Pinout Cat5 cable
Jacks A+B are paralleled
Pin Signal
1 ADAT1+ (ADAT 5+*)
2 ADAT1- (ADAT 5-*)
3 ADAT2+ (ADAT 6+*)
4 ADAT2- (ADAT 6-*)
5 ADAT3+ (ADAT 7+*)
6 ADAT3- (ADAT 7-*)
7 ADAT4+ (ADAT 8+*)
8 ADAT4- (ADAT 8-*)
* ADX-64: Connections 5-8
Power supply
8..24V DC 5W, Polarity:
Plug type: ID 2.5mm, OD 5.5mm
Mechanical dimensions 19“ rack case 1U
Depth: 60mm
