82
use and maintenance Pegaso 650 I.E.
!$*534).'4(%#/,$34!24
#/.42/,
Carefully read p. 55 (MAINTENANCE).
Have the accelerator control cables
checked by an aprilia Official Dealer after
the first 1000 km (625 mi) and successively
every 6000 km (3750 mi).
The idle stroke of the cold start control (1)
must be 2–3 mm, measured on the edge of
the control itself.
If not, proceed as follows:
◆ Position the vehicle on the stand, see p.
52 (POSITIONING THE VEHICLE ON
THE STAND).
◆ Withdraw the protection element (2).
◆ Loosen the lock nut (3).
◆ Rotate the adjuster (4) in such a way as
to restore the prescribed value.
◆ After the adjustment, tighten the lock nut
(3) and check the idle stroke again.
◆ Put back the protection element (2).
aCAUTION
After the adjustment, make sure that the
rotation of the handlebar does not mod-
ify the engine idling rpm.
