APRILIA RSV4 1100 Factory User Manual

See also
Removing the
rear wheel
•
Unscrew and remove the lower screw
fixing the chain pad and retrieve the
washers.
•
Remove the chain skid (1).
Stand
SIDE STAND
Pos. Description Type Quantity Torque Notes
1 Screws for fastening the stand to the
frame
M10 2 45 Nm (33.19 lb ft) Loct. 243
2 Linear switch retaining screws and
nuts
M5 2 4 Nm (2.95 lb ft) -
3 - Spring retaining pin on stand - 1 10 Nm (7.38 lb ft) Loct. 243
4 Stand fastening pin - 1 15 Nm (11.06 lb ft) Loct. 243
5 Pin for retaining springs on stand pin - 1 22 Nm (16.23 lb ft) Loct. 243
- Rear stand bushing retaining screw M6 2 7 Nm (5.16 lb ft) -
RSV4 1100 Factory Chassis
CHAS - 445

APRILIA RSV4 1100 Factory Specifications

General

Front Tire	120/70 ZR 17
Rear Tire	200/55 ZR 17
Engine Type	V4, 4-stroke
Displacement	1078 cc
Max Power	217 hp (159.5 kW) @ 13, 000 rpm
Max Torque	122 Nm @ 11, 000 rpm
Transmission	6-speed
Fuel System	Electronic fuel injection
Front Suspension	Öhlins NIX 43 mm fork, fully adjustable
Rear Suspension	Öhlins TTX, fully adjustable monoshock
Front Brake	Dual 330 mm discs, Brembo Stylema calipers
Rear Brake	220 mm disc, Brembo caliper
Dry Weight	199 kg
Fuel Tank Capacity	18.5 liters
Frame	Aluminum dual beam chassis
Seat Height	851 mm
Electronics	APRC (Aprilia Performance Ride Control) including traction control, wheelie control, launch control, quick shift
