Undo and remove the screw inside of
the point indicated in the figure.
•
Unscrew the fixing screws (2) together
with the nuts (3).
•
Disconnect the connector (4).
•
Remove the support (5).
Air box
FILTER BOX COVER REMOVAL
•
Remove the control unit complete with
support.
•
Undo the four screws fixing the injec-
tors unit to the filter box
•
Remove the injectors from the filter box
Bodywork RSV4 RR-RF
BODYW - 534
