Engine side swinging arm plastic bushing
shim:
3.5 ± 0.05 mm
Chassis side swinging arm plastic bushing
shim:
3.5 ± 0.05 mm
Length of the internal swinging arm spacer on
the frame side:
290 ± 0.1 mm
Length of the swinging arm tube on the chas-
sis side:
283 ± 0.1 mm
- Lubricate roller casings and the plastic bushings with grease
- Insert the spacers
- Assemble the two arms with the relative bolt in the position shown in the picture
- Adjust the bolt as shown in the picture
- Position the chassis side swinging arm with the most protruding part pointing towards the silent block
side as shown in the picture
Recommended products
AGIP GREASE PV2 Ivory smooth-textured, slightly-stringy anhydrous calcium-base grease.
TL 9150 066, symbol NATO G 460
Refitting
- To refit, perform the removal operations in reverse.
- Grease the bearings and the rolling parts with the recommended grease.
-Complete the fitting by tightening the nuts on the relative bolts to the proper tightening torque.
See also
Shock absorbers
Suspensions SR MAX 125 ie
SUSP - 228
