Replacement
-Remove the oil filler cap «A».
- Unscrew the oil drainage cap «B» and drain out
all the oil.
- Screw in the drainage cap again and fill the hub
with the prescribed oil.
Recommended products
AGIP GEAR SAE 80W-90 Lubricant for gear-
boxes and transmissions.
API GL-4
Characteristic
Transmission oil
250 cm³
Locking torques (N*m)
Hub oil drainage screw 15 to 17 Nm
Air filter
To remove them, proceed as follows:
1. Unscrew the 9 fixing screws «A»;
2. Remove the air filter «B»
CAUTION
IF THE VEHICLE IS USED ON DUSTY ROADS IT IS NEC-
ESSARY TO CARRY OUT MAINTENANCE CHECKS OF
THE AIR FILTER MORE OFTEN TO AVOID DAMAGING THE
ENGINE.
Cleaning:
SR MAX 125 ie Maintenance
MAIN - 39
