use and maintenance TUONO 1000
USA
28
ARRANGEMENT OF THE MAIN ELEMENTS
KEY
1) Fairing lug
2) Side fairings
3) Adjustable steering damper
4) Left headlight
5) Clutch fluid reservoir
6) Left rearview mirror
7) Engine oil reservoir plug
8) Left side body panel
9) Rider seat
10)Battery
11)Main fuse carrier (30A)
12)Passenger seat-glove/tool kit
compartment lock
13)Passenger left footrest
(snapping, closed/open)
14)Drive chain
15)Swingarm
16)Rider left footrest
17)Side stand
18)Gear shift lever
19)Engine oil filter
20)Engine oil tank
21)Engine oil level
1
4
3
2
21 20
5 6 7 8 9 10 11
17 18 16 15 14
12
13
19
APRum_TUONO_MY05_####.book Page 28 Monday, January 9, 2006 2:53 PM
