APsmart RSD-S-PLC - RSD-S-PLC Installation Steps; RSD-S-PLC Mounting Procedures

Step 1: Install the RSD-S-PLC.
Buckle RSD-S-PLC on the PV module frame.
DC input - DC input +
DC output - DC output +
Mounting brackets
A. Front buckle
B. Back buckle
Note: Both installations can be installed anywhere on the PV module frame.
7
