Neutrik® powerCON
Male Connector
Neutrik® powerCON Female
Locking Connector
To disconnect the Neutrik® powerCon cable, pull back on the yellow release tab on the
cable connector, and rotate the connector counterclockwise.
1. Powering by Batteries
V-Mount Battery
Anton Bauer Battery
Batteries: Voltage 12~16.8V; Recommended ≥15A continuous discharge.
The LS 300x can be operated using a single battery for up to half of the mxture’s maximum
output. Plugging the light into AC power
or using two batteries allows you to utilize the light’s full output. When powering the light from a
single battery, you mu t install the s
battery on the right side of the of the control box, or the light will not turn on.
Do not use non-14.4v batteries (batteries with voltages outside of the 12-16.8V range). Using
higher voltage batteries will damage the power supply and the lighting mxture.
Only use batteries that support the necessary continuous current discharge special cations
mentioned above. If non-compatible batteries are used, the batteries will enter a protection state
and the lighting mixture will not operate as intended.
