Aqara Door and Window Sensor User Manual

English
* Keep the surface clean and dry.
Installation gap less than 22 mm
Model: MCCGQ11LM
Dimensions: 41 × 22 × 11 mm (1.61 × 0.87 × 0.43 in.)
Wireless Protocol: Zigbee
Battery: CR1632
Maximum Detection Distance: 22 mm (0.87 in.)
Operating Temperature: -10° – +50°C (14° – 122°F )
Operating Humidity: 0 – 95% RH, no condensation
Maximum Transmit Power (Zigbee): 9.99 dBm
Working Frequency: 2400 MHz – 2483.5 MHz
Specications

Aqara Door and Window Sensor Specifications

General

Wireless Protocol	Zigbee 3.0
Model	MCCGQ11LM
Battery Life	Up to 2 years
Compatibility	Apple HomeKit
Battery Type	CR1632
Operating Temperature	-10°C to 45°C
Operating Humidity	0% to 95% (non-condensing)
Installation	Adhesive
Dimensions	41 x 22 x 11 mm (main body)
