Aqara Motion Sensor User Manual

English
The recommended installation height is 1.2 m to 2.1 m. If the
installation height is below 1.2 m, the detection area will decrease; if
above 2.1 m, the detection area might have blind spots.
*
7m4.5m
2.1m
2m
Effective Detection Area — Side View
Effective Detection Area — Top View
170°
Note that the lens should be aligned with the detection area when
installing, and placed or pasted as close as possible to the edge of a
table or cabinet.
*

Aqara Motion Sensor Specifications

General

Model	RTCGQ11LM
Detection Angle	170°
Battery Type	CR2450
Wireless Protocol	Zigbee
Battery Life	Up to 2 years
Detection Distance	7 meters
Operating Humidity	0 – 95%RH, no condensation
Compatibility	Aqara Home, Apple HomeKit
Operating Temperature	-10°C~+45°C (14°F~113°F)
