Aquabot XTREME - BOTTOM LID ASSEMBLY; POWER SUPPLY FEATURES

4
Figure 3
BOTTOM LID ASSEMBLY
12. Bottom Lid
12a. Wire Frame Bag Support
12b. “H” - Float (Fig. 3a)
12c. Side Pocket Floats (Fig. 3a)
12d. Debris Intake Port Flap
12e. Filter Bag
12a
12
12e
12
12c
12d
12b
12d
* Fuse Holder is located on the back of the Power Supply
POWER SUPPLY FEATURES
Figure 4
15a. Power Supply Handle
15b. Power Switch - ON/OFF
15c. Fuse Holder*
15d. Power Supply (Housing)
15e. Floating Cable Socket
15f. Power Supply Cable
15a 15d 15e 15f
15b
