Quartz™ Bath Installation Guide 15
Connect the bath waste to a suitable waste pipe.
5
Oer the outlet body assembly into position at the rear of the
bath ensuring the rubber washer is correctly aligned between the
outlet body assembly and bath wall.
6
Ensuring the rubber washer is correctly aligned, pass the overflow
filler outlet through the bath and secure to the body assembly.
7
Remove the relevant inlet blanking plug and attach the flexible
hose to the blended inlet connection.
8
PTFE thread tape MUST be used to guarantee a watertight seal.
9
Connect the flexible hose to the blended supply pipe ensuring suitable non
restrictive double check valves (not supplied) are fitted in line with current Water
Supply Regulations.
