Quartz™ Bath Installation Guide 16
WASTE PIPE EXTENSION KIT
If required for larger baths, a 900mm waste pipe conversion kit is available from
the Aqualisa Customer Service Department. Please contact our Customer Service
Department on 01959 560010.
Unscrew the clamping nut and remove the waste pipe from the
waste assembly.
1
Remove the clamping nut and sealing washer from the waste pipe and set aside.
2
Carefully cut down the length of the waste pipe, and disconnect
from the outlet assembly, ensuring not to damage the outlet.
3
To reassemble, push the longer waste pipe into position over the outlet, and secure it in
place using a jubilee clip (not supplied).
NOTE: The waste pipe may need to be softened by running it under hot water, to ensure it
slides over the outlet.
4
Please do not leave the bath filler running unattended. Although the overflow will remove
excess water once the bath is overfilled, this may not be sucient to prevent the bath from
overflowing (depending on system conditions).
If you have any queries regarding the installation of this product please contact the
Aqualisa Customer Service Department on 01959 560010.
