Specifications
Damage Level: 1000 V/m, continuous field or
pulsed field
Ranges: Single range
Data returned from probe: X, Y, Z axes, and
composite
Power Requirements: Laser powered from
FI7000 interface
Dimensions: Approx. 5.7 x 5.7 x 5.7 cm (2.25 x
2.25 x 2.25 in); 2.92 cm (1.15 in) in DIA spheri-
cal housing; 3.18 cm (1.25 in) sensor radome
per axes
Weight: Approx. 62.5 g (2.2 oz)
Operating Temperature Range: 10°C to 40°C
(50°F to 104°F) @ 5% to 95% RH non-
condensing
Temperature Stability: +0.5 dB over operating
temperature range
Fiber Optic Connectors: Two E2000 compact
duplex connectors at 1 meter, includes fiber op-
tic verification loop.
Calibration Data: Accredited Calibration Report
supplied with probe
Measurement Data Processing: The pulse ampli-
tude measurement is smoothed before being
sampled and digitized. The smoothing process
has a time constant of 300 msec.
Relative Flatness (field aligned with sensor axes):
±2.5 dB, 800 MHz-3 GHz; ±3.0 dB, 3.0 GHz-
3.6 GHz
Amplitude Accuracy (field aligned with sensor
axes):
Without correction factors applied: ±1.5 dB @ 1
GHz;
With correction factors applied: Typical expand-
ed measurement uncertainty (95% confidence
interval), 0.8 dB, 800 MHz–1 GHz; 1.4 dB,
1GHz–3.6 GHz
Response Time/Sampling Rate (through FI7000):
20 msec/up to 50 samples per second at
FI7000, USB and GPIB only
Isotropic Deviation (measured at the ortho an-
gle): ±1.0 dB @ 1 GHz. For improved accura-
cy, this probe should be used with a single axis
aligned with the E-field being measured.
Operating Range: 80–800 V/m
Linearity, 80 to 800 V/m: ±0.5 dB
Pulse width: 1 to 100 microseconds
Pulse Period: Up to 5 milliseconds between puls-
es (greater than 200 Hz pulse rate)
Pulse Duty: 0.02% to 2%
Pulse Measurement Variation: Over Range of
Pulse Width, Period, and Duty relative to a 10
microsecond pulse width and 1 millisecond pulse
period (1kHz pulse rate, 1% duty): ±0.5 dB/–1.0
dB typical
Page 2
Specifications
To order AR Products, call 215.723.8181. For an applications engineer call:800.933.8181. Direct to Service call: 215.723.0275 or
email: service@arworld.us For Faxing Orders:866.859.0582 (Orders Only Please) info@arworld.us
Approved for public release by AR RF/Microwave Instrumentation 102914
PL7004
Electric Field Probe
for Pulsed Fields
800MHz–3.6GHz
80–800 V/m
User–selectable
X, Y, Z Axes
