ARAG DigiWOLF 4628405 - Power Supply and Battery Replacement

7
2.4 Power supply
DigiWolf is powered by 2 AA batteries type LR6 (alkaline) or FR6 (Li-Fe S2).
2.4.1 Battery replacement
0.0 l/min
1
2
0.0 l
To insert or replace the batteries, proceed as follows:
1) Remove the lid of the battery compartment (A) loosening the 4 screws (B);
2) Remove the battery support (C) and replace the batteries, respecting their polarity (as indicated).
3) Fit the support back in its housing and ret the lid by tightening the 4 screws without forcing them, taking care not to crush or break
the wires in the battery case and that the lid seal remains in its seat.
A
B
C
To avoid damaging the device, replace low batteries as soon as this symbol is displayed .
Remember to remove the batteries when the device is not going to be in use for a long period.
Use only the recommended type of batteries. Do not use combinations of different types of batteries (old and new, carbon and
alkaline, etc.). Do not try to recharge the batteries.
ARAG is not liable for damage to the equipment, persons, animals or things caused by failure to observe the above instructions.
Do not dispose of exhausted batteries in the environment. Dispose of in a suitable container.
Fig. 11
Fig. 10
When the batteries are low, the symbol will blink on the display.
INSTALLATION
