Araknis Networks AN-210/310-SW-F/R Manual
Product Manual
Table of Contents
4 - Device Layout
1 Gbps
Link/Act
AN-210-SW-R-8-POE
1 2 3 4 5 6 7 8 9F 10F
AN-210-SW-R-8-POE
AN-210-SW-F-8-POE
1 Gbps
Link/Act
AN-310-SW-R-8-POE
1 2 3 4 5 6 7 8 9F 10F
AN-310-SW-F-8-POE
AN-310-SW-R-8-POE
AN-310-SW-F-8-POE
1. Power LED – On: system is up.
O: system is down.
2. 1Gbps LED – On: port connected at 1000Mbps speed.
O: port is connected at 10/100Mbps speed.
3. Link/Act LED – On: port is connected to another device.
Blinking: packets are running through the port.
O: port is not connected to a device.
AN-210-SW-C-8-POE
Note – The 1Gbps LED behavior may be configured to indicate other information. See instructions
in section “10 - System Settings” on page <?>.
