Araknis Networks AN-210/310-SW-F/R Manual
Product Manual
Table of Contents
5 - Hardware Installation
Mounting
Figure 2. Mounting Methods
Rack Mount Wall Mount Shelf Mount
A B C
Note – The switch must be wall mounted with the Ethernet ports facing either the floor or the
ceiling. Do not mount the switch with the ports facing to the side.
Note – Do not stack other equipment on top of the switch to avoid possible interference or
damage.
Note – Mounting is the same for models with both front- and rear-facing ports.
