TOOLS REQUIRED
Basic tool kit, drill, 10mm and 12mm drill bits.
FITTING THE 9,000lb WINCH
1. Place the bull bar on a suitable stand.
2. To place the winch clutch handle in a convenient location the winch gearbox must be rotated 4 hole spacings,
144 degrees, in an anti-clockwise direction when viewed from the gearbox end. Place the winch on its end and
remove all gearbox bolts. Gently raise the gearbox just enough to rotate it. Do not completely remove the
gearbox and avoid damaging the gasket. Refit all bolts and tighten. (Refer to diagram 1.)
NOTE: The winch handle is positioned near the bottom of the bull bar. The gearbox is situated on the left hand side
of the bull bar (as viewed from inside the vehicle). The cable spools from the bottom.
