3.4) The foam sealing block is to be
an interference fit with the
underside of the side tub rail
and fit firmly in place as shown.
Position the top edge of the
foam block to avoid covering
weld nuts in the tub.
3.5) Use neutral cure non-acetic
silicon to fill gaps and seal
edges all around foam block
and tub.
3.6) Silicon seal all around foam
block as per picture.
Repeat steps 3.1 to 3.6 for
sealing the tub using the
right-hand tub corner sealing
foam block.
