4.17) Use an alcohol wipe (6602018) to clean
away rust inhibitor residue.
4.18) Cut a pair of rubber tub bridge seals
(668PM005) down to 35mm width as
shown.
4.19) Apply neutral cure silicon to the ends of
the front mount rail bracket both sides, to
fill the gaps between the bracket and the
side tub rails.
Clean surrounding surfaces well using an
alcohol wipe (66020018) to remove
silicon from surrounding surfaces at the
join.
