Note: Silicon is to run behind rubber
corner block seal (668PE057R/L).
Clean up excess and make silicon
neat.
6.24) Cable tie the (6821293) cable tie base to
the canopy loom at the front LH outer
corner of the canopy, in the location
shown (on the base of the rubber
grommet) tight enough to not allow it to
fall down the loom and in the orientation
shown.
