2.7) If the tailgate plastic liner is
present, remove the eight T20
torx drive screws.
2.8) Remove the top rubber
extrusion from the tailgate liner
and discard it.
Leave the bottom rubber
retaining extrusion in place.
Do not remove the tailgate
liner from tailgate.
REMOVE 8 SCREWS
FROM THE TAILGATE
LINER
REMOVE TOP RUBBER
EXTRUSION FROM
THE TAILGATE
LEAVE THE LINER
AND BOTTOM LINER
RUBBER EXTRUSION
IN PLACE
