5
4 INTRODUCTION TO YOUR ARB FRIDGE
The key components of your ARB Fridge are identified below in Figures 1 to 4.
Figure 1 Front of fridge Figure 2 Rear of fridge
Figure 3 Interior cabinet
1. Lid
12. 100-240V AC power socket
2. Cooling vent LH
13. 12/24V DC power socket
3. Lid latch x 2
14. Compliance plate and serial number
4. Front carry handle
15. Gas strut
5. Control panel
16. Drain plug
6. Padlock position
17. LED cabinet light
7. Rubber feet x 4
18. Reversible basket
8. Socket for wireless transmitter
19. Secondary cooling cabinet
9. Hinge x 2
20. Primary cooling cabinet
10. Rear carry handle
21. Basket divider
11. Cooling vent RH
1
5
2
3
4
9
10
11
12
13
6
15
16
17
21
18
19
14
20
