ARCA ECOTROL 8C D Series User Manual

ARCA Regler GmbH 4 Nameplate
Series 8C D / 6H D 13 / 2811.2018 / 1.0
4 Nameplate
Illustration2: Nameplate
1 App. no. / Serial no.
2 Type designation / Year of manufacture
3 Valve design
4 Nominal size
5 Nominal pressure
6 Flow coefficient, characteristic curve
7 Bore diameter
8 -
9 Material of housing / trim
10 Actuator function
11 Actuator type
12 Max. actuation pressure
13 Actuation pressure range
14 Type code for actuator / angle of rotation
Place of installation
The nameplate is attached to the actuator yoke or the actuator head.
Serial no.
The serial no. of the valve is stamped on the neck flange of the housing.
If it differs from the type plate, the serial no. on the housing is binding.
Illustration3: Serial no.
