ARCA ECOTROL 8C D Series - 6 Sectional Drawings; Parts List

ARCA Regler GmbH 6 Sectional drawings
Series 8C D / 6H D 15 / 2811.2018 / 1.0
6 Sectional drawings
Some versions of the valve are illustrated below. Further versions are
possible by combining the different components.
Drawing details
X see [10.3] Stem sealing
6.1 Parts list
Item Name
1 Housing
2 Bonnet
20 * Seat
26 * Plug (compl.)
50 * Stem
65 Guide bush
80 * Bolt / threaded bolt
81 * Nut
117 * Wiper ring
143 * Gasket
152 Stuffing box screw
154 * Base ring
156 * Seal set
164 * Plain bearing
166 * O-ring
180 * Sealing element
182 Retainer
504 Clamping sleeve
* recommended spare part / wearing part
