ARCA ECOTROL 8C D Series User Manual

ARCA Regler GmbH 12 Torque tables - bolted connections
Series 8C D / 6H D 25 / 2811.2018 / 1.0
12 Torque tables - bolted connections
12.1 Screws according to DIN EN ISO 4017/4014, DIN 939
Thread Torque [Nm]
A2-70
M8 13
M10 30
M12 50
M16 120
M20 230
M24 390
M27 580
12.2 Screws according to DIN 2510
Thread Torque [Nm]
A2-70 1.7709 1.7218 1.4923 1.4913
M10 * 19 23 19 25 32
M12 35 40 30 45 60
M14 50 65 50 70 90
M16 90 110 85 120 150
M20 170 200 160 220 280
M24 280 350 280 380 470
M27 410 500 400 550 690
M30 580 710 570 780 970
M33 770 950 760 1000 1300
M36 990 1200 960 1300 1600
* Works standard
12.3 Screws according to ASME B16.5
Thread Torque [Nm/lbf ft]
A193B7 A193B8 A193B7M
½“-UNC 19/14 46/34 73/54
⅝“-UNC 35/26 90/66 140/103
¾“-UNC 50/37 150/111 250/184
⅞“-UNC 90/66 250/184 400/295
1“-UNC 170/125 370/273 600/443
1⅛“-UNC 280/207 520/384 840/620
1¼“-UNC 990/730 730/538 1200/885
