Truth table
MUTE Main Asel Z2 Asel
ADC
/RST
VCR PVR TAPE 5 4 3 2 1 0 5 4 3 2 1 0
x x x x x x x x x x 1 1 1 0 0 0 Z2 CD
x x x x x x x x x x 1 1 1 0 0 1 Z2 AV
x x x x x x x x x x 1 1 1 0 1 0 Z2 SAT
x x x x x x x x x x 1 1 1 0 1 1 Z2 DVD
x x x x x x x x x x 1 1 1 1 0 0 Z2 VCR
x x x x x x x x x x 1 1 1 1 0 1 Z2 PVR
x x x x x x x x x x 1 1 1 1 1 0 Z2 TAPE
x x x x x x x x x x 0 0 0 1 1 1 Z2 Phono
x x x x x x x x x x 0 0 1 1 1 1 Z2 Aux
x x x x x x x x x x 0 1 0 1 1 1 Z2 GND
x x x x x x x x x x 0 1 1 1 1 1 Z2 AM/FM
x x x x x x x x x x 1 0 0 1 1 1 Z2 DAB/Sirius
x x x x x x x x x x 1 0 1 1 1 1 Z2 Net
x x x x x x x x x x 1 1 0 1 1 1 Z2 Spare
x x x x x x x x x x 1 1 1 1 1 1 Z2 GND
x x x x 1 1 1 0 0 0 x x x x x x Main CD
x x x x 1 1 1 0 0 1 x x x x x x Main AV
x x x x 1 1 1 0 1 0 x x x x x x Main SAT
x x x x 1 1 1 0 1 1 x x x x x x Main DVD
x x x x 1 1 1 1 0 0 x x x x x x Main VCR
x x x x 1 1 1 1 0 1 x x x x x x Main PVR
x x x x 1 1 1 1 1 0 x x x x x x Main Tape
x x x x 0 0 0 1 1 1 x x x x x x Main Phono
x x x x 0 0 1 1 1 1 x x x x x x Main Aux
x x x x 0 1 0 1 1 1 x x x x x x Main GND
x x x x 0 1 1 1 1 1 x x x x x x Main AM/FM
x x x x 1 0 0 1 1 1 x x x x x x Main DAB/Sirius
x x x x 1 0 1 1 1 1 x x x x x x Main Net
x x x x 1 1 0 1 1 1 x x x x x x Main Spare
x x x x 1 1 1 1 1 1 x x x x x x Main GND
x 1 1 0 x x x x x x x x x x x x Tape out mute
x 1 0 1 x x x x x x x x x x x x PVR out mute
x 0 1 1 x x x x x x x x x x x x VCR out mute
x 1 1 1 x x x x x x x x x x x x No loop mute
0 x x x x x x x x x x x x x x x ADC reset
1 x x x x x x x x x x x x x x x ADC running
