Archgard Optima 40 - Replacement Parts List - General Parts

Optima 40 34
REPLACEMENT PARTS LIST ARCHGARD OPTIMA 40
Item # Item Description Qty Unit
200-0166 Owner’s Manual 1 EA
840-0005 Top Louver (grill) assembly (Metallic Black) 1 EA
840-0004 Bottom Louver (grill) assembly (Metallic Black) 1 EA
300-0030 Hinge Self Closing Brass 2 EA
800-0060 Air Shutter Assembly 1 EA
314-0131 Air Shutter Gasket 1 EA
800-0031 Wiring Harness assembly for On/Off Rocker Switch 1 EA
305-0019 On/Off Rocker Switch 1 EA
700-0152 Exhaust Restrictor 1 EA
Fan Components
305-0012 Power Cord 8’ (2.43 M) 1 EA
305-0013 Fan - Speed Control (Rheostat) 1 EA
305-0021 Fan - Thermodisk (fan sensor) 110
0
F. (43
0
Celsius) 1 EA
305-0024 Fan - Fan with motor and blades. 120VAC, 115V, 24watt 1 EA
702-0047 Fan - Thermodisk mounting bracket 1 EA
702-0050 Fan - Heat Shield 1 EA
Flat Glass Door
BAD-40 Flat Glass Door. Includes ceramic glass, gasket and door
frame
1 EA
Ceramic Brick
311-0017 Ceramic Brick Liner - Right Side 1 EA
311-0018 Ceramic Brick Liner - Left Side 1 EA
311-0060 Ceramic Brick Liner - Rear 1 EA
702-0044 Brick Panel Clips 2 EA
