! WARNING
Indicates a potential hazard that could
result in a serious injury or death.
20
2020
20
Sound Judgment
Cargo Limitations
Limit the ATV to the load capacity rat-
ings identified in the following chart. So
if you’re weighing in at over 165 lb (75
kg) when you ride, leave some of that
extra cargo at home. The combined
weight limit, including you, your rack
cargo, and your trailer, is a specified
amount, so consult the Load Capacity
Ratings Chart and monitor it carefully.
Extra weight on the ATV will also throw
you off balance if it’s not distributed
evenly, side-to-side and front-to-rear. If
you have 200 lb (91 kg) on the rear rack
only and you’re heading up an incline,
shifting your own weight forward isn’t
going to do enough to compensate for
that cargo sitting over the back tires.
Cargo has such a huge affect on ATV
handling that you need to pay a lot of
attention to your speed. Even on really
level areas, you should keep it under 10
mph (16 kph) if you’ve got a trailer
attached. Avoid uneven terrain. Also,
consider that your braking distance is
going to increase with the more weight
you carry.
Load Capacity Ratings
Chart
Max Payload - Mass of vehicle in run-
ning order together with rider subtracted
from maximum technically permissible
mass declared by the manufacturer.
Tongue Weight - Weight on trailer
tongue.
Tongue and Accessory Weight - Must
be included as part of the front and rear
rack weights.
Towing Limit - Total weight of trailer
and all cargo in the trailer.
Speedrack
When installing Speedrack accesso-
ries, make sure to read and carefully
follow the instructions provided in
each kit.
NOTE:
Use extra caution when
operating an ATV with additional
loads such as accessories and/or
cargo. Handling of the ATV may be
adversely affected. Reduce speed
when adding additional loads
.
Arctic Cat ATV Load Capacity Ratings
Item Specifications
350
(kg)
425
(kg)
Max Payload 220 231
Front Rack (max) 34 34
Rear Rack (max) 68 68
Tongue Weight 13 14
Towing Limit 131,5 139.5
! WARNING
POTENTIAL HAZARD
Overloading the ATV or carrying or tow-
ing cargo improperly.
WHAT CAN HAPPEN
Could cause changes in ATV handling,
which could lead to an accident.
HOW TO AVOID THE HAZARD
Never exceed the stated load capacity
for the ATV.
Cargo should be properly distributed
and securely attached.
Reduce speed when carrying cargo or
pulling a trailer. Allow greater distance
for braking.
Always follow the instructions in this
Operator’s Manual for carrying cargo or
pulling a trailer.
