Division II - Operation/
Maintenance
DIVISION II - OPERATION/MAINTENANCE
ATV Specifications
Specifications subject to change without notice.
ENGINE 350 425
Type Four-Cycle/Oil and Air Cooled Four-Cycle/Liquid Cooled
Bore x Stroke 81 mm x 71.2 mm (3.19 x 2.80
in.)
89 mm x 71.12 mm (3.5 x
2.8 in.)
Displacement 366 cc (22.33 cu in.) 442.45 cc (27 cu in.)
Spark Plug Type NGK CR8E
Spark Plug Gap 0.7-0.8 mm (0.028-0.032 in.)
Brake Type Hydraulic w/Brake Lever Lock and Auxiliary Brake
CHASSIS
Length (Overall) 215 cm (84.6 in.)
Height (Overall) 119 cm (46.9 in.) 117.6 cm (46.3 in.)
Width (Overall) 109 cm (42.9 in.)
Suspension Travel
(Front/Rear)
17.7 cm (7.0 in.)
Tire Size (Front) 24 x 8-12 25 x 8-12
Tire Size (Rear) 24 x 10-12 25 x 10-12
Tire Inflation Pressure 0,8 bar
MISCELLANY
Dry Weight (Approx) 288 kg 316 kg
Gas Tank Capacity (Rated) 15.1 L (4.0 U.S. gal.)
Differential Capacity 275 ml (9.3 fl oz)
Coolant Capacity N/A 2.9 L (3.0 U.S. qt)
Rear Drive Capacity 250 ml (8.5 fl oz)
Gasoline (Recommended) EU Unleaded 91 Octane
Engine Oil (Recommended) Arctic Cat ACX All Weather (Synthetic)
Differential/Rear Drive
Lubricant
SAE Approved 80W-90 Hypoid
Taillight/Brakelight 12V/5W/21W
Headlight 12V/35W (4)
License Plate Light 12V/5W
Turn Signal - Front 12V/10W
Turn Signal - Rear 12V/5W
Position Light - Front 12V/5W
Starting System Electric
