5. Pour recommended oil into each
filler hole.
NOTE: If the gear case has a level
plug, fill to the threads of the level
plug. If the gear case has only a fill
plug, fill to within 2.5 cm (1 in.) of
the threads of the fill plug.
CF113A
CF116A
NOTE: Arctic Cat recommends
the use of genuine Arctic Cat lubri-
cants.
6. Install the filler plugs and level
plugs.
Hydraulic Hand Brake
738-420B
Brake Fluid
Check the brake fluid level in the brake
fluid reservoir. If the level in the reser-
voir is not visible in the sight glass, add
DOT 4 brake fluid.
738-420A
NOTE: If the sight glass appears
dark, there is a sufficient amount of
fluid in the reservoir.
Emergency/Parking Brake
Check to make sure the emergency/park-
ing brake engages properly and that the
brake (when engaged) locks the wheels.
1. Engage the emergency/parking
brake.
2. Attempt to push the ATV.
! WARNING
Be sure to inspect the hydraulic
brake system before each use.
Always maintain brakes according
to the Maintenance Schedule.
CAUTION
Be careful not to spill any fluid when
filling the brake fluid reservoir. Wipe
away spilled fluid immediately.
