1. Clock/Engine Hour Meter - The
clock function indicates time in the
12-hour mode; the hour meter indi-
cates the total time the ATV has run
and cannot be reset to zero. To set
the clock, use the following proce-
dure.
A. With the ignition switch ON,
press and release the Mode But-
ton (3) until the Clock/Engine
Hour Meter (1) is displayed;
then (if necessary) press and
release the Set/Reset Button (4)
to select the clock display.
B. Press and hold the Set/Reset
Button (4) until the minutes stop
scrolling and the hour display
starts to scroll. Momentarily
release when the correct hour is
displayed; then repeatedly press
and release the Set/Reset Button
(4) until the correct minutes are
displayed.
NOTE: Clock memory power is
supplied through the 15-amp acces-
sory fuse and verified during gauge
“power-up” and reset. In the event
of clock memory power failure
(blown fuse, etc.), the gauge will
“power-up,” reset, and shut down
repeatedly until clock memory
power is restored. Always check
the 15-amp accessory fuse if this
gauge condition is noted.
NOTE: The engine hour meter will
not activate until engine speed
exceeds 500 RPM.
2. Temperature Indicator - If the engine
coolant temperature exceeds the nor-
mal operating range, the temperature
icon will begin flashing and the
LCD will go blank for 30 seconds;
then the LCD will return to normal.
However, the temperature icon will
continue to flash.
NOTE: High engine RPM, low
vehicle speed, or heavy load can
raise engine temperature. Decreas-
ing engine RPM, reducing load, and
selecting an appropriate transmis-
sion gear can lower the tempera-
ture.
NOTE: Debris in front of the
engine (or packed between the
cooling fins of the radiator) can
reduce cooling capacity. Using a
garden hose, wash the radiator and
the engine to remove any debris
restricting air flow.
3. Mode Button - Shifts the gauge
through three set-up modes: speed-
ometer/tachometer, distance, and
time.
NOTE: The Mode Button must be
pressed and released to shift
modes. Approximately two seconds
after the Mode Button is released,
the digital gauge will return to full
display.
4. Set/Reset Button - In conjunction
with the Mode Button, sets and
resets various displays on the digital
gauge. Also used to shift from
speedometer function to tachometer
function on the speedometer/
tachometer gauge.
5. Fuel Level Indicator - Indicates
approximate amount of gasoline in
the gas tank.
NOTE: When the bottom segment
flashes, approximately 3.5 L (0.92
U.S. gal.) of gasoline remains in the
tank.
CAUTION
Continued operation with high
engine temperature may result in
engine damage or premature wear.
CAUTION
Arctic Cat does not recommend
using a pressure washer to clean
the radiator core. The pressure may
bend or flatten the fins causing
restricted air flow, and electrical
components on the radiator could
be damaged. Use only a garden
hose with spray nozzle at normal tap
pressure.
