5.5 Alarm
5.5.1 MR90
When a pedestrian and/or an obstacle is detected in the relevant detection
zone, BLAXTAIR® triggers:
• a visual alarm and audible alarm on the screen
• a visual alarm with the LED and/or an audible alarm with an
external buzzer (option)
• 1 or 2 accessory outputs.
The option installed may differ from the following standard alarm, which is
given as an example:
Monitor
Additional
LED
(option)
Additional
Buzzer
(option)
Visual
alarm
Sounding
alarm
Icon
No obstacles or
pedestrians in the
zones
None
None
None
No obstacles or
pedestrians in the
‘’obstacle’’ zone. No
pedestrians in the
“pedestrian” zone
None
None
None
Obstacles or
pedestrians in the
« obstacle » zone
No obstacles in the
“obstacle” zone.
Pedestrians in the
“pedestrian” zone
Software or
hardware technical
problem
None
Ref.
Chapter
8
None
