5.5.2 MR180
5.5.2.1 Twin monitor configuration
Both monitors have the same status (except in the case of failure). The table
below sums up the possible situations.
Head 1
Head 2
Monitor 1
Monitor 2
Additional
Led/buzzer
+
+
+
5.5.2.2 Optional configuration: single monitor for
MR180
Both videos are displayed simultaneously on a single split screen.
When a detection occurs, the video of the Sensor Head in alarm mode is
displayed in full screen automatically.
Once the alarm stops, both videos are displayed again in split screen mode.
The following table sums up the different views on the screen during
detections.
