Head 1
Head 2
Monitor
5.5.3 External alarm (output) - Option
Customers may require an external alarm on the vehicle (beacon, strobe,
audible alarm, etc.). Two different external alarms can be setup. Generally,
the following setup is implemented:
• Output 1: All Obstacles. External alarm is triggered when an
obstacle is detected in the ‘obstacle zone’ or when a pedestrian
is detected in the ‘pedestrian zone’ and detection is active (e.g.
reverse selected);
• Output 2: Pedestrian Only. External alarm is triggered when a
pedestrian is detected in the ‘pedestrian zone’ and detection is
active (e.g. reverse selected). No obstacle detection.
Head 1
Head 2
Head 1
Head 2
Head 1
