3.2 Connection overview
3.2.1 Basic configuration: BLAXTAIR® MR90
Video (VGA)+ sound
+ Monitor Power
Sensor Head Control
+ power + data
Processing Unit
Power Supply
Ground
+ Battery
+ Ignition
+ Digital
Ethernet I/F
