3.2.2 Alternate configuration: BLAXTAIR® MR90-A
Video (VGA)+ sound
+ Monitor Power
Sensor Head n°1 Control + power + data
Sensor Head n°2
Control+power+data
Processing Unit
Power Supply
Ethernet I/F
