3.2.3 Dual configuration: BLAXTAIR® MR180
Important notice:
• Accessory outputs of both Processing Units are identical and linked
together: i.e. if one Processor detects a pedestrian, outputs of the
other Processor are triggered simultaneously.
• USB for maintenance give access only to the Processor it is
connected to.
• Ethernet I/F is not available in this configuration as it is used for
communication between both Processing Units.
• Inputs (power and digital inputs) of both Processors should be
connected identically.
