3.3 Processing unit connections
Fast Ethernet
MR180 I/F
RS I/O
Power
supply
USB Connection
for maintenance
and LED
Accessory
output
(0/12V)
Sensor
Head n°2
Display
VGA + sound
Sensor
Head n° 1
