3.4 Power connection and analog inputs
The inputs (E1, E2 and E3) are normally used for activating the detection (e.g.
reverse gear). See Installation Manual.
3.5 Head connection
The Blaxtair 3 Sensor Head has one single external connector. It is connected
to the Processing Unit through the specific connection harness. This link
provides power and control messages from the Processing Unit to the Sensor
Head and the data flow from the Sensor Head to the Processing Unit.
