Page #2 background image
Arduino® Nano ESP32
2 / 20 Arduino® Nano ESP32 Modified: 17/07/2023
Features
Xtensa® Dual-core 32-bit LX7 Microprocessor
Up to 240 MHz
384 kB ROM
512 kB SRAM
16 kB SRAM in RTC (low power mode)
DMA Controller
Power
Operating voltage 3.3 V
VUSB supplies 5 V via USB-C® connector
VIN range is 6-21 V
Connectivity
Wi-Fi®
Bluetooth® LE
Built-in antenna
2.4 GHz transmitter/receiver
Up to 150 Mbps
Pins
14x digital (21x including analog)
8x analog (available in RTC mode)
SPI(D11,D12,D13), I2C (A4/A5), UART(D0/D1)
Communication Ports
SPI
I2C
I2S
UART
CAN (TWAI®)
Low Power
7 μA consumption in deep sleep mode
240 μA consumption in light sleep mode
RTC Memory
Ultra Low Power (ULP) Coprocessor
Power Management Unit (PMU)
ADC in RTC mode
Question and Answer IconNeed help?

Do you have a question about the Arduino Nano ESP32 and is the answer not in the manual?

Arduino Nano ESP32 Specifications

General IconGeneral
MicrocontrollerESP32-S3
Flash Memory16 MB
Digital I/O Pins14
Analog Input Pins8
Operating Voltage3.3 V
Input Voltage (VIN)6-21V
DC Current per I/O Pin40 mA
Dimensions18 x 45 mm
USBUSB-C
Wi-Fi802.11 b/g/n
Architecture32-bit
Clock Speed240 MHz
CommunicationUART, SPI, I2C
BluetoothBluetooth® LE
