Arduino Nano RP2040 Connect User Manual

Arduino®NanoRP2040Connect
Arduino®NanoRP2040Connect/Rev.01-03/05/20212/20
TargetAreas
InternetofThings(IoT),machinelearning,prototyping,
Features
RaspberryPiRP2040Micrcontroller
133MHz32bitDualCoreArm®Cortex®-M0+
264kBon-chipSRAM
DirectMemoryAccess(DMA)controller
Supportforupto16MBofoff-chipFlashmemoryviadedicatedQSPIbus
USB1.1controllerandPHY,withhostanddevicesupport
8PIOstatemachines
ProgrammableIO(PIO)forextendedperipheralsupport
4channelADCwithinternaltemperaturesensor,0.5MSa/s,12-bitconversion
SWDDebugging
2on-chipPLLstogenerateUSBandcoreclock
40nmprocessnode
Multiplelowpowermodesupport
USB1.1Host/Device
InternalVoltageRegulatortosupplythecorevoltage
AdvancedHigh-performanceBus(AHB)/AdvancedPeripheralBus(APB)
U-blox®NinaW102WiFi/BluetoothModule
240MHz32bitDualCoreXtensaLX6
520kBon-chipSRAM
448KbyteROMforbootingandcorefunctions
16MbitFLASHforcodestorageincludinghardwareencryptiontoprotectprograms
anddata
1kbitEFUSE(non-erasablememory)forMACaddresses,moduleconfiguration,
Flash-Encryption,andChip-ID
IEEE802.11b/g/nsingle-band2.4GHzWiFioperation
Bluetooth4.2
IntegatedPlanarInverted-FAntenna(PIFA)
4x12-bitADC
3xI2C,SDIO,CAN,QSPI
Memory
AT25SF128A16MBNORFlash
QSPIdatatransferrateupto532Mbps
100Kprogram/erasecycles

Arduino Nano RP2040 Connect Specifications

General

Microcontroller	Raspberry Pi RP2040
Flash Memory	16 MB
SRAM	264 KB
Clock Speed	133 MHz
Digital I/O Pins	20
Analog Input Pins	8
PWM Pins	20
UART	2
SPI	1
I2C	1
Operating Voltage	3.3V
Wireless and Bluetooth	u-blox NINA-W102
Microphone	Yes
Analog Output Pins	0
External Interrupts	All digital pins
Weight	5 g
WiFi	802.11b/g/n
USB	Micro USB
IMU	6-axis
Dimensions	45 mm x 18 mm
Bluetooth	Yes (u-blox NINA-W102)
