Arduino®NanoRP2040Connect
Arduino®NanoRP2040Connect/Rev.01-03/05/20213/20
STLSM6DSOXTR6-axisIMU
3DGyroscope
±2/±4/±8/±16gfullscale
3DAccelerometer
±125/±250/±500/±1000/±2000dpsfullscale
Advancedpedometer,stepdetectorandstepcounter
SignificantMotionDetection,Tiltdetection
Standardinterrupts:free-fall,wakeup,6D/4Dorientation,clickanddouble-click
Programmablefinitestatemachine:accelerometer,gyroscopeandexternalsensors
MachineLearningCore
Embeddedtemperaturesensor
STMP34DT06JTRMEMSMicrophone
AOP=122.5dBSPL
64dBsignal-to-noiseratio
Omnidirectionalsensitivity
-26dBFS±1dBsensitivity
RGBLED
CommonAnode
ConnectedtoU-blox®NinaW102GPIO
Microchip®ATECC608ACrypto
CryptographicCo-ProcessorwithSecureHardware-BasedKeyStorage
I2C,SWI
HardwareSupportforSymmetricAlgorithms:
SHA-256&HMACHashincludingoff-chipcontextsave/restore
AES-128:Encrypt/Decrypt,GaloisFieldMultiplyforGCM
InternalHigh-QualityNISTSP800-90A/B/CRandomNumberGenerator(RNG)
SecureBootSupport:
FullECDSAcodesignaturevalidation,optionalstoreddigest/signature
Optionalcommunicationkeydisablementpriortosecureboot
Encryption/Authenticationformessagestopreventon-boardattacks
I/O
14xDigitalPin
8xAnalogPin
MicroUSB
UART,SPI,I2CSupport
Power

Arduino Nano RP2040 Connect Specifications

General

Microcontroller	Raspberry Pi RP2040
Flash Memory	16 MB
SRAM	264 KB
Clock Speed	133 MHz
Digital I/O Pins	20
Analog Input Pins	8
PWM Pins	20
UART	2
SPI	1
I2C	1
Operating Voltage	3.3V
Wireless and Bluetooth	u-blox NINA-W102
Microphone	Yes
Analog Output Pins	0
External Interrupts	All digital pins
Weight	5 g
WiFi	802.11b/g/n
USB	Micro USB
IMU	6-axis
Dimensions	45 mm x 18 mm
Bluetooth	Yes (u-blox NINA-W102)
