Arduino Portenta H7 Series User Manual

Arduino® Portenta H7 Lite Connected
6 / 20 Arduino® Portenta H7 Lite Connected Modified: 11/05/2022
Component Details
2× 32-bit timers with up to 4
IC/OC/PWM or pulse counter and
quadrature (incremental) encoder
input (up to 240 MHz)
2× 16-bit advanced motor control
timers (up to 240 MHz)
10× 16-bit general-purpose timers
(up to 240 MHz)
5× 16-bit low-power timers (up to
240 MHz)
4× watchdogs (independent and
window)
2× SysTick timers
RTC with sub-second accuracy and
hardware calendar
True random number generators
(3 oscillators each)
96-bit unique ID
External memories SDRAM (optional) Up to 64 MByte
QSPI Flash (optional) Up to 128 MByte
USB-C High speed (optional/FUll Speed
USB)
Host and Device operation
Power Delivery support (optional)
DisplayPort
High Density connectors 1x10/100 Ethernet with PHY
1x CAN
4x UART (2 with flow control)
3x I2C
1x SD Card
1x SPI
1x I2S
1x PDM input
2 lane MIPI DSI output
8 bit parallel camera interface
10x PWM output
7x GPIO
8x ADC inputs with separate VREF
ATECC608 Microchip Crypto
(optional)
Protected storage for up to 16
Keys, certificates or data
Hardware support for asymmetric
sign, verify, key agreement –
ECDSA: FIPS186-3 Elliptic Curve
Digital Signature

Arduino Portenta H7 Series Specifications

General

Processor	Dual-core Arm Cortex-M7 and Cortex-M4
Clock Speed	480 MHz (Cortex-M7), 240 MHz (Cortex-M4)
Flash Memory	2 MB
SRAM	1 MB
Operating Voltage	3.3V
Input Voltage (recommended)	5V
EEPROM	No
Operating Temperature	-40°C to +85°C
Dimensions	66.04 mm x 25.4 mm
RAM	8 MB SDRAM
Analog Output Pins	2
Connectivity	WiFi, Bluetooth, Ethernet
WiFi	802.11 b/g/n
Bluetooth	Bluetooth 5
USB	USB 2.0
Ethernet	10/100 Ethernet
Camera Interface	Parallel camera interface
CAN	Yes
SPI	Yes
I2C	Yes
UART	Yes
