Page 34
216.0
205.0
65.5
57.5
Rubber mounting feet
SCN
K-Bus
12
No Vx V~
163.0
All dimensions in mm
57.5
216.0
205.0
179.0
181.0
174.0
4 off mounting lugs
163.0
K-Bus
12
No Vx V
AUXILIARY SUPPLY
VOLTAGE
4 (Typ)
SCN
All dimensions in mm
Figure 5a: Outline drawing for KITZ 101
Figure 5b: Outline drawing for KITZ 102
