Areva MiCOM P225 - The AUX OUTPUT RLY Submenu

Menu of the HMI P225/EN HI/B11
MiCOM P225 Page 33/48
8.7 The AUX OUTPUT RLY submenu
AUTOMAT. CTRL
Press the ! and " keys to enter the AUTOMAT. CTRL
menu.
AUX OUTPUT RLY
To move about in the AUX OUTPUT RLY, press the !
and " keys.
To enter the other submenus, press the % and $ keys.
THERM OV. 5 4 3 2
0 0 0 0
To allocate the « thermal tripping information »
(protection against thermal overloads) to one (or more)
of the outputs n° 2 to 5 :
press the # key, allocate the value 1 under the letter by
pressing the ! and " keys to increase or decrease,
then confirm the selection using the # key.
θ ALARM 5 4 3 2
0 0 0 0
Allocation of the θ
ALARM
thermal alarm threshold .
θ FORBID. 5 4 3 2
START 0 0 0 0
Allocation of the thermal block start signal θ
FORBID START
.
I >> 5 4 3 2
0 0 0 0
Allocation of the I>> instantaneous threshold (short-
circuit).
t I >> 5 4 3 2
0 0 0 0
Allocation of the tI>> time-delayed threshold (short-
circuit).
IO> 5 4 3 2
0 0 0 0
Allocation of the Io> instantaneous threshold (earth
fault).
t IO> 5 4 3 2
0 0 0 0
Allocation of the tIo> time-delayed threshold (earth fault).
IO>> 5 4 3 2
0 0 0 0
Allocation of the Io>> instantaneous threshold (earth
fault).
t IO>> 5 4 3 2
0 0 0 0
Allocation of the tIo>> time-delayed threshold (earth
fault).
t I2 > 5 4 3 2
0 0 0 0
Allocation of the tI2> time-delayed threshold
(unbalance).
t I2 >> 5 4 3 2
0 0 0 0
Allocation of the tI2>> time-delayed threshold
(unbalance).
EXCEX LG 5 4 3 2
START 0 0 0 0
Allocation of the tI
start
time-delayed threshold (excessively
long starts).
t Istall 5 4 3 2
0 0 0 0
Allocation of the tI
stall
time-delayed threshold (stalling of
the rotor when the motor is running).
LOCKED 5 4 3 2
ROTOR 0 0 0 0
Allocation of the function « rotor locked at start ».
t I < 5 4 3 2
0 0 0 0
Allocation of the I< time-delayed threshold (undercurrent
/ loss of load).
START NB 5 4 3 2
LIMIT 0 0 0 0
Allocation of the function « limitation of the number of
starts ». »
T betw 2 5 4 3 2
start 0 0 0 0
Allocation of the T
betw 2 start
time delay (minimum time
between 2 starts function).
t RTD1 5 4 3 2
ALARM 0 0 0 0
Allocation of the t
RTD1 ALARM
time-delayed threshold
(temperature protection : optional).
