Technical Guide P92x/EN FT/E11
User Guide
MiCOM P921-P922-P923 Page 27/110
7.5 “ALARM” sub-menu
This menu allows the user to select the reset mode of the instantaneous informations
and to configure the battery alarms.
To gain access to the "ALARMS" menu from the default display, press 2 once, 6
once, 2 once and 6 3 times (P921) or 4 times (P922) or 5 times (P923).
7.5.1 HMI description
ALARMS
Heading of "ALARMS" submenu.
INST. SELF-RESET ?
NO
Description : display the RESET mode of the instantaneous
alarms.
Range : YES/NO
Note : if choosing YES, the instantaneous alarms will be
reset automatically (self-reset).
If choosing NO, the reset will be done manually.
ALARMS BATTERY =
NO
Description : displays the ALARM battery message
Range : YES/NO
Note : the messages are : "RAM ERROR" or "BATTERY FAIL"
in case of Ram error and battery failure.
