11. CONTROL FUNCTIONS
To gain access to the “AUTOMAT.CTRL” menu from the default display, press 2
once and 6 5 times.
The accessible sub-menus are then indicated below :
AUTOMAT. CTRL
82828282
6
TRIP OUTPUT RLY
6
LATCH OUTPUTS
6
BLOCKING LOG1 t
6
BLOCKING LOG2 t
6
4 4 4 4 4
And :
AUTOMAT. CTRL
82 8282
6
AUX OUTPUT RLY
6
LATCH OUTPUT AND LOGIC
6
T DELAY
6
4 4
RELAYS EQUAT
4
EQUATION
4
And :
AUTOMAT. CTRL
8282
6
INPUTS
6
4 4
CB SUPERVISION
11.1 "TRIP OUTPUT RLY" Menu
This sub-menu makes it possible to assign to the trip output contact (RL1) part or all
the selected time-delayed information.
In order to assign an information to the trip output contact, please go to the cell
corresponding to the selected information and press the 5 key. Select the
configuration (YES or NO) with the 2 and 8 keys. Validate with the 5 key.
