P92x/EN FT/E11 Technical Guide
User Guide
Page 56/110 MiCOM P921-P922-P923
11.1.1 MiCOM P921 - P922 and P923 : common information
To gain access to the “AUTOMAT.CTRL” menu from the default display, press 2
once, 6 5 times (P921) or 6 times (P922 and P923) and 2 once.
TRIP OUTPUT RLY
Heading of the “TRIP OUTPUT RLY” menu
TRIP tV<=
NO
Description : selection of the time-delayed information “tV<”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV<<=
NO
Description : selection of the time-delayed information “tV<<”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV<<<=
NO
Description : selection of the time-delayed information
“tV<<<”, which will be sent to the RL1 output contact
Range : YES / NO
TRIP tV>=
NO
Description : selection of the time-delayed information “tV>”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV>>=
NO
Description : selection of the time-delayed information “tV>>”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV>>>=
NO
Description : selection of the time-delayed information
“tV>>>”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV0>=
NO
Description : selection of the time-delayed information “tV0>”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV0>>=
NO
Description : selection of the time-delayed information
“tV0>>”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV0>>>=
NO
Description : selection of the time-delayed information
“tV0>>>”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP tAUX1 =
NO
Description : selection of the time-delayed information
“tAUX1”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP tAUX2 =
NO
Description : selection of the time-delayed information
“tAUX2”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP EQUATION A =
NO
Description : selection of the “A” logic equation result, which
will be sent to the RL1 output contact
Range : YES/NO
